## how to design sin wave in varilog?

This is pure electronics like Processor, transistor, diode, ROM, RAM related discussion..
Posts: 2
Joined: Tue Jul 22, 2014 6:09 pm
Contact:

### how to design sin wave in varilog?

Can we design analog circuit using verilog?
How can I check waveform of sine wave ?

Guest

### Re: how to design sin wave in varilog?

You can write below code to design sin wave.

Code: Select all

`module sine_cos(clk, reset, en, sine, cos);   input clk, reset, en;   output [7:0] sine,cos;   reg [7:0] sine_r, cos_r;   assign      sine = sine_r + {cos_r[7], cos_r[7], cos_r[7], cos_r[7:3]};   assign      cos  = cos_r - {sine[7], sine[7], sine[7], sine[7:3]};   always@(posedge clk or negedge reset)     begin         if (!reset) begin             sine_r <= 0;             cos_r <= 120;         end else begin             if (en) begin                 sine_r <= sine;                 cos_r <= cos;             end         end     endendmodule // sine_cos`

Guest

### Re: how to design sin wave in varilog?

If you want to generate sin stimulus in a testbench, you can create sin wave in other tools such as matlab or SPW then write out the data to a file.

finally you can read the file in testbench written in verilog.

Guest

### Re: how to design sin wave in varilog?

Two capabilities in SystemVerilog allow for the creation of a module that can produce a sine wave as an output: the ability to pass real values through port connections and DPI.

Obviously, to produce a sine wave, you need access to the sin function. This is where DPI is handy to add the math functions to your simulation. Here is an example of a package I created to contain the math functions:

package math_pkg;

//import dpi task C Name = SV function name

import "DPI" pure function real cos (input real rTheta);

import "DPI" pure function real sin (input real rTheta);

import "DPI" pure function real log (input real rVal);

import "DPI" pure function real log10 (input real rVal);

endpackage : math_pkg

The import"DPI" construct defines a new function that you can use in your code that refers to a C function. In the case of the math functions listed above, they already exist in the libmath.so library built into Linux and so there is no additional code required. Now that I have my math functions, I can create my module.

Code: Select all

`module sine_wave(output real sine_out);  import math_pkg::*;   parameter  sampling_time = 5;  const real pi = 3.1416;  real       time_us, time_s ;  bit        sampling_clock;  real       freq = 20;  real       offset = 2.5;  real       ampl = 2.5;   always sampling_clock = #(sampling_time) ~sampling_clock;   always @(sampling_clock) begin    time_us = \$time/1000;    time_s = time_us/1000000;  end  assign sine_out = offset + (ampl * sin(2*pi*freq*time_s));endmodule `
